Quickly find the shelving system you need How to choose the best storage solution for your application Quick Shelving Guide (Only shelving and racking products are included in this guide) Page Product Max Loading Capacity (UDL) Max Height Max Width Max Depth Most suitable for Shelf Bay / Frame* (mm) (mm) (mm) Warehouse Storeroom Workshop Office Garage 6 Clicka 265 265kg 1325kg 1770 1200 600 4 4 4 6 Clicka Galvanised 265kg 1325kg 1980 1200 600 4 4 4 4 4 8 Kwikrack 300kg 1500kg 2500 1500 600 4 4 4 4 16 MediumRivet 300kg 2800kg 3660 1830 1220 4 4 4 16 Heavy Rivet 600kg 2800kg 3660 2440 1220 4 4 4 24 J Rivet 150kg 2800kg 3660 1220 610 4 4 4 38 Rivet Workstation 400kg 600kg 1830 2440 915 4 4 4 40 Rivet Workbench 400kg 600kg 915 2440 915 4 4 4 42 Rivet Mobile Workbench 300kg 300kg 880 1830 915 4 4 4 44 Rivet Packing Bench/Workstation 300kg 300kg 1830 1830 1830 4 4 4 46 EXPO 4G 200kg 2500kg 7000 1150 600 4 4 4 47 EXPO 4 200kg 2500kg 7000 1150 600 4 4 4 50 EXPO 4D 200kg 2500kg 7000 1150 600 4 4 4 52 EXPO 3 300kg 2500kg 7000 1300 800 4 4 4 56 Delta Plus 120kg 600kg 2530 986 600 4 4 60 Midispan 750kg 8800kg 6000 2400 1200 4 4 4 66 TS Longspan 950kg 3900kg 4016 2754 1233 4 4 78 Cantilever 600kg 2200kg 2964 1500 2180* 4 4 4 80 Vertical Racking Variable Variable 2550 1800 810* 4 4 4 82 Pallet Racking 3790kg 11000kg 6000* 3300* 1100* 4 120 Kanban Shelving 80kg 400kg 1830 915 610 4 4 4 4 Heavy Duty MediumDuty Light Duty *See product specific page for more info Suitability shown is a suggestion only, the use of the products is not limited by the applications specificed in this table. 4 Find the be t s orag solutions for your h me or workpl ce SHELVING GUIDE
How to find the best storage solution The storage environment. We have tried to make selecting the right system storage system simple and easy. With clear and intuitive icons on each page, it’s easy to make a quick selection. Need more information? No problem. Highly detailed technical information is available for each product. Our application icons quickly and simply indicate the environment the system is most suitable for. Application can range from the office to retail to the warehouse. Most of our products are suitable for multiple environments - this is illustrated by the icons shown below. From left to right these icons illustrate - height, width, depth, application, construction and loading These small target icons appear under some images, in pricelists and support graphics. They link the pictured product with its actual size in the pricelist. Find your solutions. In addition to our key application and loading icons, we illustrate further information using the icons shown below. You will find these icons at the start of each major product section. The icons below illustrate dimensions (Height, Width, Depth), application, construction as well as more detailed loading information. The information you’ll find below each of these icons act as a summary for the product section that follows, saving you time when you’re finding the perfect storage solution. Tube Load Shelf Load Bay Load Levels X Height Delivery Width Depth The meaning of the colours: Per Level Please note the usage indicated is only a suggestion and doesn’t limit the use of the product in different environments What exactly do you need to store? For most workplaces there is generally a wide variety of products that come in a wide range of sizes and loading capacities. It is important to have a clear specification of the weight and dimensions of the goods, this will give a clear understanding as to the type of shelving required. From this information you will be able to establish the shelf and total bay capacity needed, the overall size of the shelf required to store the various items. Note Capacities stated on the icons are based on maximum uniformly distributed loads (UDL).. The total bay load is dependent on several factors such as shelf pitch (distance between levels), height of the first shelf & actual size of the shelves. 450 KG Light Duty Medium Duty Heavy Duty Guarantee All of our products come with a guarantee. You will find the relevant guarantee detailed on the first page of each product section. Guarantee Guarantee Assembly Time Assembly time is now noted on all shelving. This can range from 5 – 20 minutes, based on two competent people building a single bay. Assembly Assembly Additional Features Our product range is vast and extremely diverse, as a result each product has its own features and benefits. Our icons visualise some key features. Boltless Recycled Office Retail Storeroom Warehouse Workshop SHELVING GUIDE 5
Best for Garage, Storeroom or Office | up to 265kg UDL/shelf Clicka shelving offers a solution to your storage needs, as well as your budget. It is simple to erect yet has all the strength you are likely to require and is available in 265kg or 175kg shelf capacities. Manufactured with high quality materials and finish. Whether you are fitting out the home or workplace, our Clicka Sheving kits offers strength and simplicity • Best value shelving system 265kg or 175kg shelf capacity at great prices • Superior quality and strength Robust and strong • Easy to assemble and re-configure Build a bay in less than 10 minutes with just a rubber mallet • Fast 48hr delivery There when you want it – without fail • Will suit any application A versatile range, ideal for home, office, garage or storeroom CLICKA SHELVING Guarantee Delivery Boltless Assembly Clicka 265 with 15 Archive Boxes H x W x D (mm) Code Shelf Load (kg) Price 1880 x 1200 x 450 CL265E/AK15 265kgs £214.20 Clicka 265 Archive 1770 x 1200 x 450 with 15 archive boxes Archive Box 270 H x 350 W x 430 D (mm) Each bay is delivered flat-packed. Price includes uprights, upright connectors, plastic feet, beams, shelf supports and MDF shelves. The Archive bay includes 15x flat-packed archive boxes with lids. MALLET £5.79 Rubber Mallet Connect two bays back to back or side by side to create a run of bays CL3/CLIP Set of 4 £2.90 Bay Connector 6 CLICKA SHELVING Best for Garage, Storeroo or Office | up to 265kg DL/shelf
Clicka 265 1770mm Uprights come split into two – allowing the system to be packed flat and used as two benches if required. Clicka 175 1800mm Clicka Galvanised 1980mm Clicka 265 900mm, 1200 mm Clicka 175 900mm Clicka Galvanised 1200mm Clicka 265 depths 300mm, 450mm, 600mm Clicka 175 450mm, 600mm Clicka Galvanised 600mm Environment Garage, Storeroom or Office Usage General Shelving, Archive, Workbench Split Uprights: Steel Blue RAL5002 Beams: Steel Blue RAL5002 Clicka 265 & 175 5 x MDF Shelves Clicka Galvanised RB350M Mesh Decking Clicka 265 Max Bay Load 1325kg Clicka 265 Shelf Load up to 265kg UDL Clicka 175 Shelf Load up to 175kg UDL Clicka Galvanised up to 265kg UDL Our best value shelving – compare our quality and our prices Heights Widths Depths Application Construction Loadings Clicka 265 (MDF) H x W x D (mm) Code Shelf Load(kg) Price 1800 x 900 x 300 CL265A/BG 265kgs £87.09 1800 x 900 x 450 CL265B/BG 265kgs £111.77 1800 x 900 x 600 CL265C/BG 265kgs £133.03 1800 x 1200 x 300 CL265D/BG 265kgs £112.11 1800 x 1200 x 450 CL265E/BG 265kgs £135.09 1800 x 1200 x 600 CL265F/BG 265kgs £161.49 Clicka Galvanised (Mesh Decking) H x W x D (mm) Code Shelf Load(kg) Price 1980 x 1200 x 600 RB350M 265kgs £214.20 Clicka 175 (MDF) H x W x D (mm) Code Shelf Load(kg) Price 1800 x 900 x 450 CL175A 175kgs £52.40 1800 x 900 x 600 CL175B 175kgs £60.90 Depths (mm) 300 450 600 900 1200 Widths (mm) Available Sizes £87.09 Each bay is delivered flat-packed. Price includes uprights, upright connectors, plastic feet, beams, desck supports and shelves £214.20 £52.40 Available Sizes Depths (mm) 450 600 900 Widths (mm) CLICKA SHELVING 7 Storeroom Workshop Office
Best for Warehouse, Storeroom or Workshop | up to 300kg UDL/shelf Our Kwikrack offers a robust and cost effective storage solution for any application. The unique 6 fold channel beam offers shelf capacities of 300kgs with a shelf height of only 54mm. The design of the beam allows for an inset chipboard decking design with interlocking deck supports for a strong and robust shelf level. The system is simple to erect, yet has all the strength you are likely to need. The bays just tap together with a rubber mallet so you can organise your storage in a fraction of the time it can take with more traditional systems. With a build time of just 10 minutes, large installations will be completed in no time at all. • Easy to assemble and re-configure Build a bay in 10 minutes with a rubber mallet • Will suit any application A versatile range, ideal for home, garage or industry • Best value shelving system With shelf capacities of up to 300kgs at great prices KWIKRACK 8 KWIKRACK t
Heights Widths Depths Application Construction Loadings Standard Bay Height (mm) 2000 Other Available Heights (mm) 2500 Widths (mm) 1000, 1200, 1500 Depths (mm) 300, 450, 600 Environment Warehouse, Storeroom, Workshop Usage Multipurpose Storage, Heavy & Bulky Items, Archiving Uprights: Steel Blue RAL5010 Beams: Steel Galvanised Shelves/Decks Chipboard 12mm Shelf UDL 200, 250, 300kg Max Bay Load up to 1500kgs KWIKRACK 9 Storeroom Workshop Warehouse
10 KWIKRACK Best for Warehouse, Storeroom or Workshop | up to 300kg UDL/shelf Have you seen our labelling options? See Page 162-165 Three bay run of Kwikrack 2000 x 1000 x 450 Industrial racking for any application Plan your layout Nominal Bay Width (mm) Clear Entry (mm) Bay Width (mm) Bay width with plastic feet (mm) Bay width with metal feet (mm) 1000 920 1000 1011 1013 1200 1120 1200 1211 1211 1500 1420 1500 1511 1511 Nominal Bay Depth (mm) Clear Entry (mm) Bay Depth (mm) Bay Depth with plastic feet (mm) Bay Depth with metal feet (mm) 300 220 300 311 311 450 370 450 461 461 600 520 600 611 611 Kwikrack beam profile Overall Height = H + 5mm Shelf Pitch = every 33.33mm Clear opening between levels = Total Shelf Pitch - 54mm First shelf level = 90mm FFL Bay Capacity = 1500kgs MALLET £5.79 Rubber Mallet RR5/WBKT £1.50 Wall Bracket RR5/SET4 Set of 4 £6.02 Metal Feet FFM8X50 M8x50 £1.68 Floor Fixing
Price includes uprights, plastic feet, perimeter beams, deck supports and chipboard decks for all levels KWIKRACK 11 Storeroom Workshop Warehouse 300kg +For Taller Bays Add Price Extra Height Code Price Bays 2500mm KWB/25/--/--/5/BGV £14.12 Wide Open Bays +Add Extra Shelves H x W x D (mm) Bay Code Shelf Load (kg) Bay Price Shelf Code Additional Shelf Price W1000mm 2000x1000x300 KWB/20/10/03/5/BGV 300 £146.50 KWS/10/03/GV £17.54 2000x1000x450 KWB/20/10/04/5/BGV 300 £175.15 KWS/10/04/GV £23.27 2000x1000x600 KWB/20/10/06/5/BGV 300 £198.88 KWS/10/06/GV £28.01 W1200mm 2000x1200x300 KWB/20/12/03/5/BGV 250 £164.73 KWS/12/03/GV £21.18 2000x1200x450 KWB/20/12/04/5/BGV 250 £191.64 KWS/12/04/GV £26.57 2000x1200x600 KWB/20/12/06/5/BGV 250 £218.27 KWS/12/06/GV £31.89 W1500mm 2000x1500x300 KWB/20/15/03/5/BGV 200 £196.28 KWS/15/03/GV £27.49 2000x1500x450 KWB/20/15/04/5/BGV 200 £233.90 KWS/15/04/GV £35.02 2000x1500x600 KWB/20/15/06/5/BGV 200 £267.18 KWS/15/06/GV £41.67 Kwikrack with Archive Boxes Wide open bays with heavy duty shelves Kwikrack bay 2000 x 1000 x 600mm £146.50 Guarantee Delivery DAYS Boltless Assembly Pricing based on 5 levels
Offers incredible value for money, whilst offering amazing strength and rigidity. The system is simple to build with all parts being tapped together using a rubber mallet. All components are joined via the heavy duty rivet and key hole slot which offers a simple and effective way to assemble the racking. There are no nuts and bolts and the bays require no bracing therefore offering uninterrupted access on all four sides. Bays are available in various heights up to 3660mm high. With the average time to assemble a bay being just 5 minutes, you will be amazed at how easy it is to create large installations in no time at all. All bays are ready for immediate dispatch and will be delivered in 5 working days. • Best Selling system Offers the widest choice of sizes, all at great value • Easy to build and re-configure Simply tap together with a rubber mallet • Strong and sturdy With shelf capacities up to 600kgs, it easily copes with heavy goods • No nuts, bolts or screws Simple and quick to erect, with no fuss • Strong epoxy paint finish Designed to give years of service and withstand heavy use • Will suit any application Versatile and expandable, suits a wide range of industries • Guaranteed delivery in 5 days There when you need it, without fail RIVET RACKING 12 RIVET RACKING Best for Warehouse, Storeroom or Workshop | up to 600kg UDL/shelf
Heights Widths Depths Application Construction Loadings Heavy & Medium Rivet Incredible value for money, amazing strength and rigidity. Bays come complete with 3 or more levels and have a central deck support on bays 1220mm to 2135mm wide, whilst 2440mm wide bays have two per level. J Rivet Our J rivet system has unbeatable strength at an incredible price. It is also manufactured to the highest quality. The shallow J beam profile (only 30mm thick) gives increased storage capacity whilst maintaining excellent strength. Standard Bay Height (mm) 1830 Other Available Heights (mm) 1980, 2135, 2440, 2745, 3050, 3660 Uprights can be cut to a specific size Heavy Rivet Widths (mm) 915, 1220, 1525, 1830, 2135, 2440 Medium Rivet Widths (mm) 1830 J Rivet Widths (mm) 915, 1220 Heavy Rivet Depths (mm) 305, 457, 610, 762, 915, 1220 Medium Rivet Depths (mm) 305, 457, 610, 762, 915, 1220 J Rivet Depths (mm) 305, 457, 610 Environment Warehouse, Storeroom, Workshop Usage Multipurpose Storage, Heavy & Bulky Items, Archiving, Garment Storage, Reel Storage Uprights: Steel Blue RAL5010 Beams: Steel Grey RAL7038 **Orange RAL2002 Shelves/Decks Chipboard 15-16mm **Heavy Rivet Only Heavy Rivet Shelf UDL 400-600kg Medium Rivet Shelf UDL 230-300kg J Rivet Shelf UDL 120-150kg Max Bay Load up to 2800kg Guarantee Delivery DAYS Boltless Assembly Guarantee Delivery DAYS Boltless Assembly 13 RIVET RACKING Storeroom Workshop Warehouse
We have multiple solutions to different storage problems, if you are unsure what’s best for you, please contact us. Best for Warehouse, Storeroom or Workshop | up to 600kg UDL/shelf Design and plan your Rivet Racking layout i i W+17mm H D+17mm W+17mm D+17mm D+17mm 38.1mm 2mm Rivet Upright Rivet Racking Bay Loading (kgs) Calculating Exact Dimensions of the Bay & Run of Bays J Rivet A 98mm 125mm 30mm A Minimum First Shelf Level Height H Nominal Height* W Nominal Width* D Nominal Depth* CE Clear Entry between uprights * Dimensions used in price tables Front View (side by side connected bays) Footprint Side View (back to back connected bays) B Shelf Pitch - Distance between levels C Clear Entry - Useable space between shelf levels D Shelf Thickness - Beam and chipboard e.g. 320mm(Height of stored items) + 88mm(Heavy Rivet) / 38.1 = 10.7 rounded to 11 x 38.1 = 419.1mm Shelf Pitch 88mm see below how to calculate exact Shelf Pitch B minus D B minus D B How can you calculate exact Shelf Pitch (B) Height of item stored + Shelf Thickness divided by 38.1 = Round decimal up to the next whole number and multiply by 38.1 C D Heavy Rivet For safety and stability of the bay, the first level must be attached within 200mm from the ground! H 38mm 2mm B C A A D 98 200 125 ~ ~ ~ 88 ~ 30 B C D Shelf Pitch (B) - distance between levels (mm) Maximum bay load (kg) 300 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200 450 600 750 900 1050 1200 CE=W-68mm Tie Plates Tie Plates Chipboard Shelf Chipboard Shelf 14 RIVET RACKING Best for Warehouse, Storeroom or Workshop | up to 600kg UDL/shelf
Rivet Racking can be further enhanced with mobile accessories, providing another range of solutions. Rivet Racking accessories and components 8 1 2 3 4 6 7 9 10 11 1. J Rivet Beam Decking is flush with the top of the beam Used with tubes to create rails 2. Notched Side Beam 3. Rivet Upright Uprights can be up to 3660mm high 4. Tie Plate Connects two bays together Comes as a standard with every bay 5. Plastic Feet Allows the bay to be floor fixed 6. Metal Foot Decking sits on top of the beam 7. Heavy Rivet Beam 8. Tray Shelf Reversed medium rivet ‘L’ beams 9. Chipboard Deck Rivet Racking uses 15mm and 16mm decks Allows the bay to be wall fixed 10. Wall Bracket 11. Deck Support Adds strength to shelf levels 5 RIVET RACKING GUIDE Storeroom Workshop Warehouse 15
16 HEAVY RIVET Best for Warehouse, Storeroom or Workshop | up to 600kg UDL/shelf If you’d like the Heavy Rivet in blue/orange, use code ‘BO’ when placing the order. Heavy duty industrial racking thatmeets the demands of anywarehouse, storeroomandworkshop. Rivet Racking offers incredible value for money with amazing strength and rigidity. The quality of the materials used and robust construction ensures it will meet the rigors of the toughest workplace. The vast range of bay sizes allows for a solution tomeet your storage needs and the available space. Flexibility of wide open bays and large shelf capacities enable products of varying weights and dimensions to be easily stored within a single system. Industrial racking for any application Rivet Racking 1830 x 1830 x 610mm Blue/Grey +Deck Support Detail Heavy Rivet beam profile 915, 1220 & 1525 wide Heavy Rivet beam profile 1830, 2135 & 2440 wide HEAVY RIVET Bay Colour Options For Blue Uprights with Orange Shelves add /BO to the end of your chosen price code. For Blue Uprights with Grey Shelves add /BG to the end of your chosen price code. MALLET £5.79 RR5/WBKT £1.50 RR5/SET4 Set of 4 £6.02 FFM8X50 M8x50 £1.68 RR8/SET4 Set of 4 £5.35 Rubber Mallet Wall Bracket Metal Feet Floor Fixing Tie Plate RIVET RACKING Best for Warehouse, Storer om r Workshop | up to 600kg UDL/shelf
Rivet Racking uses a central deck support which not only supports the chipboard panel but ties the front and back beams together. Wide open bays with heavy duty shelves Price includes three levels, uprights, plastic feet, face and side beams, deck supports* and chipboard decks for all levels (*except 915mm wide). 1830 2135 1980 2440 2745 3050 3660 Available Heights (mm) (width shown 915mm) +For Taller Bays Add Price Extra Height Code Price bays 1980mm RRB/19/--/--/4 £4.17 bays 2135mm RRB/21/--/--/4 £7.41 bays 2440mm RRB/24/--/--/4 £15.05 bays 2745mm RRB/27/--/--/4 £21.53 bays 3050mm RRB/30/--/--/4 £31.02 bays 3660mm RRB/36/--/--/4 £43.99 Wide Open Bays +Add Extra Shelves H x W x D (mm) Bay Code Shelf Load (kg) Bay Price Shelf Code Additional Shelf Price W915mm 1830 x 915 x 305 RRB/18/09/03/3 600 £124.39 RRS/09/03 £28.42 1830 x 915 x 457 RRB/18/09/04/3 600 £139.96 RRS/09/04 £35.08 1830 x 915 x 610 RRB/18/09/06/3 600 £154.49 RRS/09/06 £41.39 1830 x 915 x 762 RRB/18/09/07/3 600 £173.53 RRS/09/07 £49.20 1830 x 915 x 915 RRB/18/09/09/3 600 £199.05 RRS/09/09 £59.10 1830 x 915 x 1220 RRB/18/09/12/3 550 £233.67 RRS/09/12 £73.34 W1220mm 1830 x 1220 x 305 RRB/18/12/03/3 550 £154.72 RRS/12/03 £35.60 1830 x 1220 x 457 RRB/18/12/04/3 550 £178.16 RRS/12/04 £43.41 1830 x 1220 x 610 RRB/18/12/06/3 550 £200.56 RRS/12/06 £50.88 1830 x 1220 x 762 RRB/18/12/07/3 550 £228.69 RRS/12/07 £60.25 1830 x 1220 x 915 RRB/18/12/09/3 550 £261.85 RRS/12/09 £71.31 1830 x 1220 x 1220 RRB/18/12/12/3 550 £311.86 RRS/12/12 £87.98 W1525mm 1830 x 1525 x 305 RRB/18/15/03/3 500 £181.11 RRS/15/03 £44.39 1830 x 1525 x 457 RRB/18/15/04/3 500 £209.07 RRS/15/04 £53.71 1830 x 1525 x 610 RRB/18/15/06/3 500 £235.98 RRS/15/06 £62.69 1830 x 1525 x 762 RRB/18/15/07/3 500 £263.42 RRS/15/07 £71.83 1830 x 1525 x 915 RRB/18/15/09/3 500 £300.23 RRS/15/09 £84.10 1830 x 1525 x 1220 RRB/18/15/12/3 500 £357.53 RRS/15/12 £103.20 W1830mm 1830 x 1830 x 305 RRB/18/18/03/3 500 £221.92 RRS/18/03 £58.00 1830 x 1830 x 457 RRB/18/18/04/3 500 £253.69 RRS/18/04 £68.59 1830 x 1830 x 610 RRB/18/18/06/3 500 £284.25 RRS/18/06 £78.78 1830 x 1830 x 762 RRB/18/18/07/3 500 £315.16 RRS/18/07 £89.08 1830 x 1830 x 915 RRB/18/18/09/3 500 £355.62 RRS/18/09 £102.57 1830 x 1830 x 1220 RRB/18/18/12/3 450 £420.22 RRS/18/12 £124.10 W2135mm 1830 x 2135 x 305 RRB/18/21/03/3 450 £248.66 RRS/21/03 £66.91 1830 x 2135 x 457 RRB/18/21/04/3 450 £284.08 RRS/21/04 £78.72 1830 x 2135 x 610 RRB/18/21/06/3 450 £318.12 RRS/21/06 £90.06 1830 x 2135 x 762 RRB/18/21/07/3 450 £352.84 RRS/21/07 £101.64 1830 x 2135 x 915 RRB/18/21/09/3 450 £396.95 RRS/21/09 £116.34 1830 x 2135 x 1220 RRB/18/21/12/3 425 £468.66 RRS/21/12 £140.25 W2440mm 1830 x 2440 x 305 RRB/18/24/03/3 400 £280.96 RRS/24/03 £77.68 1830 x 2440 x 457 RRB/18/24/04/3 400 £323.15 RRS/24/04 £91.74 1830 x 2440 x 610 RRB/18/24/06/3 400 £364.30 RRS/24/06 £105.46 1830 x 2440 x 762 RRB/18/24/07/3 400 £422.30 RRS/24/07 £124.79 1830 x 2440 x 915 RRB/18/24/09/3 400 £476.30 RRS/24/09 £142.79 1830 x 2440 x 1220 RRB/18/24/12/3 400 £567.47 RRS/24/12 £173.18 Rivet Racking 1830 x 1525 x 762mm Blue/Orange £124.39 Guarantee Delivery DAYS Boltless Assembly Pricing based on 3 levels HEAVY RIVET 17 Storeroom Workshop Warehouse
Heavy Rivet is perfect for heavy duty items with shelf loads of up 600kg UDL 18 HEAVY RIVET Best for Warehouse, Storeroom or Workshop | up to 600kg UDL/shelf RIVET RACKING Best for Warehouse, Storer om r Workshop | up to 600kg UDL/shelf Fully adjustable, multi-purpose, heavy duty storage Rivet Racking 1830 x 2440 x 610mm Blue/Orange + Detail Bay Colour Options For Blue Uprights with Orange Shelves add /BO to the end of your chosen price code. For Blue Uprights with Grey Shelves add /BG to the end of your chosen price code. MALLET £5.79 RR5/WBKT £1.50 RR5/SET4 Set of 4 £6.02 FFM8X50 M8x50 £1.68 RR8/SET4 Set of 4 £5.35 Rubber Mallet Wall Bracket Metal Feet Floor Fixing Tie Plate
Our Heavy Rivet range is available in six different heights and six depths HEAVY RIVET 19 Storeroom Workshop Warehouse Wide Open Bays +Add Extra Shelves H x W x D (mm) Bay Code Shelf Load (kg) Bay Price Shelf Code Additional Shelf Price W915mm 1830 x 915 x 305 RRB/18/09/03/4 600 £152.81 RRS/09/03 £28.42 1830 x 915 x 457 RRB/18/09/04/4 600 £175.03 RRS/09/04 £35.08 1830 x 915 x 610 RRB/18/09/06/4 600 £195.87 RRS/09/06 £41.39 1830 x 915 x 762 RRB/18/09/07/4 600 £222.73 RRS/09/07 £49.20 1830 x 915 x 915 RRB/18/09/09/4 600 £258.15 RRS/09/09 £59.10 1830 x 915 x 1220 RRB/18/09/12/4 550 £307.00 RRS/09/12 £73.34 W1220mm 1830 x 1220 x 305 RRB/18/12/03/4 550 £190.31 RRS/12/03 £35.60 1830 x 1220 x 457 RRB/18/12/04/4 550 £221.57 RRS/12/04 £43.41 1830 x 1220 x 610 RRB/18/12/06/4 550 £251.44 RRS/12/06 £50.88 1830 x 1220 x 762 RRB/18/12/07/4 550 £288.94 RRS/12/07 £60.25 1830 x 1220 x 915 RRB/18/12/09/4 550 £333.16 RRS/12/09 £71.31 1830 x 1220 x 1220 RRB/18/12/12/4 550 £399.84 RRS/12/12 £87.98 W1525mm 1830 x 1525 x 305 RRB/18/15/03/4 500 £225.51 RRS/15/03 £44.39 1830 x 1525 x 457 RRB/18/15/04/4 500 £262.78 RRS/15/04 £53.71 1830 x 1525 x 610 RRB/18/15/06/4 500 £298.67 RRS/15/06 £62.69 1830 x 1525 x 762 RRB/18/15/07/4 500 £335.25 RRS/15/07 £71.83 1830 x 1525 x 915 RRB/18/15/09/4 500 £384.33 RRS/15/09 £84.10 1830 x 1525 x 1220 RRB/18/15/12/4 500 £460.73 RRS/15/12 £103.20 W1830mm 1830 x 1830 x 305 RRB/18/18/03/4 500 £279.91 RRS/18/03 £58.00 1830 x 1830 x 457 RRB/18/18/04/4 500 £322.28 RRS/18/04 £68.59 1830 x 1830 x 610 RRB/18/18/06/4 500 £363.03 RRS/18/06 £78.78 1830 x 1830 x 762 RRB/18/18/07/4 500 £404.24 RRS/18/07 £89.08 1830 x 1830 x 915 RRB/18/18/09/4 500 £458.19 RRS/18/09 £102.57 1830 x 1830 x 1220 RRB/18/18/12/4 450 £544.32 RRS/18/12 £124.10 W2135mm 1830 x 2135 x 305 RRB/18/21/03/4 450 £315.57 RRS/21/03 £66.91 1830 x 2135 x 457 RRB/18/21/04/4 450 £362.80 RRS/21/04 £78.72 1830 x 2135 x 610 RRB/18/21/06/4 450 £408.18 RRS/21/06 £90.06 1830 x 2135 x 762 RRB/18/21/07/4 450 £454.48 RRS/21/07 £101.64 1830 x 2135 x 915 RRB/18/21/09/4 450 £513.29 RRS/21/09 £116.34 1830 x 2135 x 1220 RRB/18/21/12/4 425 £608.91 RRS/21/12 £140.25 W2440mm 1830 x 2440 x 305 RRB/18/24/03/4 400 £358.63 RRS/24/03 £77.68 1830 x 2440 x 457 RRB/18/24/04/4 400 £414.89 RRS/24/04 £91.74 1830 x 2440 x 610 RRB/18/24/06/4 400 £469.76 RRS/24/06 £105.46 1830 x 2440 x 762 RRB/18/24/07/4 400 £547.09 RRS/24/07 £124.79 1830 x 2440 x 915 RRB/18/24/09/4 400 £619.10 RRS/24/09 £142.79 1830 x 2440 x 1220 RRB/18/24/12/4 400 £740.65 RRS/24/12 £173.18 Available in two different colour schemes Price includes four levels, uprights, plastic feet, face and side beams, deck supports* and chipboard decks for all levels (*except 915mm wide). Rivet Racking 1830 x 1830 x 610mm Blue/Grey £152.81 Guarantee Delivery DAYS Boltless Assembly Pricing based on 4 levels +For Taller Bays Add Price Extra Height Code Price bays 1980mm RRB/19/--/--/- £4.17 bays 2135mm RRB/21/--/--/- £7.41 bays 2440mm RRB/24/--/--/- £15.05 bays 2745mm RRB/27/--/--/- £21.53 bays 3050mm RRB/30/--/--/- £31.02 bays 3660mm RRB/36/--/--/- £43.99
Heavy Rivet is perfect for heavy duty items with shelf loads of up 600kg UDL 20 HEAVY RIVET Best for Warehouse, Storeroom or Workshop | up to 600kg UDL/shelf RIVET RACKING Best for Warehouse, Storer om r Workshop | up to 600kg UDL/shelf Deck Supports add strength to shelf levels Strong & Sturdy shelf capacities up to 600kg Made with high quality, robust materials £181.23 Bay Colour Options For Blue Uprights with Orange Shelves add /BO to the end of your chosen price code. For Blue Uprights with Grey Shelves add /BG to the end of your chosen price code. MALLET £5.79 RR5/WBKT £1.50 RR5/SET4 Set of 4 £6.02 FFM8X50 M8x50 £1.68 RR8/SET4 Set of 4 £5.33 Rubber Mallet Wall Bracket Metal Feet Floor Fixing Tie Plate
Rivet Racking uses a central deck support which not only supports the chipboard panel but ties the front and back beams together. Wide Open Bays +Add Extra Shelves H x W x D (mm) Bay Code Shelf Load (kg) Bay Price Shelf Code Additional Shelf Price W915mm 1830 x 915 x 305 RRB/18/09/03/5 600 £181.23 RRS/09/03 £28.42 1830 x 915 x 457 RRB/18/09/04/5 600 £210.11 RRS/09/04 £35.08 1830 x 915 x 610 RRB/18/09/06/5 600 £237.26 RRS/09/06 £41.39 1830 x 915 x 762 RRB/18/09/07/5 600 £271.93 RRS/09/07 £49.20 1830 x 915 x 915 RRB/18/09/09/5 600 £317.25 RRS/09/09 £59.10 1830 x 915 x 1220 RRB/18/09/12/5 550 £380.34 RRS/09/12 £73.34 W1220mm 1830 x 1220 x 305 RRB/18/12/03/5 550 £225.91 RRS/12/03 £35.60 1830 x 1220 x 457 RRB/18/12/04/5 550 £264.98 RRS/12/04 £43.41 1830 x 1220 x 610 RRB/18/12/06/5 550 £302.31 RRS/12/06 £50.88 1830 x 1220 x 762 RRB/18/12/07/5 550 £349.20 RRS/12/07 £60.25 1830 x 1220 x 915 RRB/18/12/09/5 550 £404.47 RRS/12/09 £71.31 1830 x 1220 x 1220 RRB/18/12/12/5 550 £487.82 RRS/12/12 £87.98 W1525mm 1830 x 1525 x 305 RRB/18/15/03/5 500 £269.90 RRS/15/03 £44.39 1830 x 1525 x 457 RRB/18/15/04/5 500 £316.49 RRS/15/04 £53.71 1830 x 1525 x 610 RRB/18/15/06/5 500 £361.35 RRS/15/06 £62.69 1830 x 1525 x 762 RRB/18/15/07/5 500 £407.08 RRS/15/07 £71.83 1830 x 1525 x 915 RRB/18/15/09/5 500 £468.43 RRS/15/09 £84.10 1830 x 1525 x 1220 RRB/18/15/12/5 500 £563.94 RRS/15/12 £103.20 W1830mm 1830 x 1830 x 305 RRB/18/18/03/5 500 £337.91 RRS/18/03 £58.00 1830 x 1830 x 457 RRB/18/18/04/5 500 £390.87 RRS/18/04 £68.59 1830 x 1830 x 610 RRB/18/18/06/5 500 £441.81 RRS/18/06 £78.78 1830 x 1830 x 762 RRB/18/18/07/5 500 £493.32 RRS/18/07 £89.08 1830 x 1830 x 915 RRB/18/18/09/5 500 £560.75 RRS/18/09 £102.57 1830 x 1830 x 1220 RRB/18/18/12/5 450 £668.41 RRS/18/12 £124.10 W2135mm 1830 x 2135 x 305 RRB/18/21/03/5 450 £382.48 RRS/21/03 £66.91 1830 x 2135 x 457 RRB/18/21/04/5 450 £441.52 RRS/21/04 £78.72 1830 x 2135 x 610 RRB/18/21/06/5 450 £498.24 RRS/21/06 £90.06 1830 x 2135 x 762 RRB/18/21/07/5 450 £556.12 RRS/21/07 £101.64 1830 x 2135 x 915 RRB/18/21/09/5 450 £629.63 RRS/21/09 £116.34 1830 x 2135 x 1220 RRB/18/21/12/5 425 £749.16 RRS/21/12 £140.25 W2440mm 1830 x 2440 x 305 RRB/18/24/03/5 400 £436.31 RRS/24/03 £77.68 1830 x 2440 x 457 RRB/18/24/04/5 400 £506.63 RRS/24/04 £91.74 1830 x 2440 x 610 RRB/18/24/06/5 400 £575.22 RRS/24/06 £105.46 1830 x 2440 x 762 RRB/18/24/07/5 400 £671.89 RRS/24/07 £124.79 1830 x 2440 x 915 RRB/18/24/09/5 400 £761.89 RRS/24/09 £142.79 1830 x 2440 x 1220 RRB/18/24/12/5 400 £913.83 RRS/24/12 £173.18 Perfect for the warehouse, storeroom or workshop Price includes five levels, uprights, plastic feet, face and side beams, deck supports* and chipboard decks for all levels (*except 915mm wide). +For Taller Bays Add Price Extra Height Code Price Bays 1980mm RRB/19/--/--/- £4.17 Bays 2135mm RRB/21/--/--/- £7.41 Bays 2440mm RRB/24/--/--/- £15.05 Bays 2745mm RRB/27/--/--/- £21.53 Bays 3050mm RRB/30/--/--/- £31.02 Bays 3660mm RRB/36/--/--/- £43.99 Rivet Racking 1830 x 915 x 457mm Blue/Orange Guarantee Delivery DAYS Boltless Assembly £181.23 Pricing based on 5 levels HEAVY RIVET 21 Storeroom Workshop Warehouse
Our Heavy Rivet is designed for even the toughest workplace. Call now to order yours 22 HEAVY RIVET Best for Warehouse, Storeroom or Workshop | up to 600kg UDL/shelf RIVET RACKING Best for Warehouse, Storer om r Workshop | up to 500kg UDL/shelf Solid Steel Decking Pricing based on 4 levels Size - HxWxD (mm) Bay Code Shelf Load/Kgs Bay Price Shelf Code Additional 1830 x 915 x 457 RRBSD/18/09/04/4 360 £289.41 RRSSD/09/04 £60.37 1830 x 915 x 610 RRBSD/18/09/06/4 360 £397.76 RRSSD/09/06 £87.46 1830 x 915 x 762 RRBSD/18/09/07/4 360 £460.73 RRSSD/09/07 £103.20 1830 x 915 x 915 RRBSD/18/09/09/4 300 £538.53 RRSSD/09/09 £122.65 1830 x 915 x 1220 RRBSD/18/09/12/4 270 £626.28 RRSSD/09/12 £144.59 1830 x 1220 x 457 RRBSD/18/12/04/4 480 £356.55 RRSSD/12/04 £77.16 1830 x 1220 x 610 RRBSD/18/12/06/4 480 £497.08 RRSSD/12/06 £112.29 1830 x 1220 x 762 RRBSD/18/12/07/4 480 £576.96 RRSSD/12/07 £132.26 1830 x 1220 x 915 RRBSD/18/12/09/4 400 £672.35 RRSSD/12/09 £156.11 1830 x 1220 x 1220 RRBSD/18/12/12/4 360 £780.01 RRSSD/12/12 £183.02 1830 x 1830 x 457 RRBSD/18/18/04/4 500 £520.93 RRSSD/18/04 £118.25 1830 x 1830 x 610 RRBSD/18/18/06/4 500 £725.83 RRSSD/18/06 £169.48 1830 x 1830 x 762 RRBSD/18/18/07/4 500 £839.51 RRSSD/18/07 £197.90 1830 x 1830 x 915 RRBSD/18/18/09/4 500 £970.09 RRSSD/18/09 £230.54 1830 x 1830 x 1220 RRBSD/18/18/12/4 450 £1,117.57 RRSSD/18/12 £267.41 1830 x 2135 x 457 RRBSD/18/21/04/4 450 £595.48 RRSSD/21/04 £136.89 1830 x 2135 x 610 RRBSD/18/21/06/4 450 £832.56 RRSSD/21/06 £196.16 1830 x 2135 x 762 RRBSD/18/21/07/4 450 £963.14 RRSSD/21/07 £228.80 1830 x 2135 x 915 RRBSD/18/21/09/4 450 £1,111.32 RRSSD/21/09 £265.85 1830 x 2135 x 1220 RRBSD/18/21/12/4 425 £1,278.71 RRSSD/21/12 £307.70 1830 x 2440 x 457 RRBSD/18/24/04/4 400 £679.53 RRSSD/24/04 £157.90 1830 x 2440 x 610 RRBSD/18/24/06/4 400 £953.19 RRSSD/24/06 £226.32 1830 x 2440 x 762 RRBSD/18/24/07/4 400 £1,105.07 RRSSD/24/07 £264.29 1830 x 2440 x 915 RRBSD/18/24/09/4 400 £1,275.01 RRSSD/24/09 £306.77 1830 x 2440 x 1220 RRBSD/18/24/12/4 400 £1,470.42 RRSSD/24/12 £355.62 all bays come with uprights, plastic feet, perimeter beams, deck supports & galvanised steel decking. Guarantee Delivery DAYS Boltless Assembly £289.41 Available Heights (mm) (width shown 1830mm) Rivet Racking 1830 x 1830 x 610mm Blue/Grey +For Taller Bays Add Price Extra Height Code Price Bays 1980mm RRB/19/--/--/- £4.17 Bays 2135mm RRB/21/--/--/- £7.41 Bays 2440mm RRB/24/--/--/- £15.05 Bays 2745mm RRB/27/--/--/- £21.53 Bays 3050mm RRB/30/--/--/- £31.02 Bays 3660mm RRB/36/--/--/- £43.99 1830 2135 1980 2440 2745 3050 3660 MALLET £5.79 RR5/WBKT £1.50 RR5/SET4 Set of 4 £6.02 RR8/SET4 Set of 4 £5.33 Rubber Mallet Wall Bracket Metal Feet Tie Plate
Did you know our Heavy Rivet Bays offer heights of up to 3660mm? 23 Storeroom Workshop Warehouse RIVET RACKING Wire Mesh Decking Pricing based on 4 levels Guarantee Delivery DAYS Boltless Assembly £239.86 Rivet Racking 1830 x 1830 x 610mm Blue/Grey MALLET £5.79 RR5/WBKT £1.50 RR5/SET4 Set of 4 £6.02 FFM8X50 M8x50 £1.68 RR8/SET4 Set of 4 £5.33 Rubber Mallet Wall Bracket Metal Feet Floor Fixing Tie Plate +For Taller Bays Add Price Extra Height Code Price bays 1980mm RRB/19/--/--/4 £4.17 bays 2135mm RRB/21/--/--/4 £7.41 bays 2440mm RRB/24/--/--/4 £15.05 bays 2745mm RRB/24/--/--/4 £21.53 bays 3050mm RRB/30/--/--/4 £31.02 bays 3660mm RRB/36/--/--/4 £43.99 Size - HxWxD (mm) Bay Code Shelf Load/Kgs Bay Price Shelf Code Additional 1830 x 915 x 457 RRBWD/18/09/04/4 600 £239.86 RRSWD/09/04 £47.98 1830 x 915 x 610 RRBWD/18/09/06/4 600 £272.74 RRSWD/09/06 £56.20 1830 x 915 x 762 RRBWD/18/09/07/4 600 £309.78 RRSWD/09/07 £65.46 1830 x 915 x 915 RRBWD/18/09/09/4 600 £355.85 RRSWD/09/09 £76.98 1830 x 915 x 1220 RRBWD/18/09/12/4 550 £428.32 RRSWD/09/12 £95.10 1830 x 1220 x 457 RRBWD/18/12/04/4 550 £288.94 RRSWD/12/04 £60.25 1830 x 1220 x 610 RRBWD/18/12/06/4 550 £328.30 RRSWD/12/06 £70.09 1830 x 1220 x 762 RRBWD/18/12/07/4 550 £373.45 RRSWD/12/07 £81.38 1830 x 1220 x 915 RRBWD/18/12/09/4 550 £425.77 RRSWD/12/09 £94.46 1830 x 1220 x 1220 RRBWD/18/12/12/4 550 £515.14 RRSWD/12/12 £116.80 1830 x 1830 x 457 RRBWD/18/18/04/4 500 £421.84 RRSWD/18/04 £93.48 1830 x 1830 x 610 RRBWD/18/18/06/4 500 £475.78 RRSWD/18/06 £106.96 1830 x 1830 x 762 RRBWD/18/18/07/4 500 £537.60 RRSWD/18/07 £122.42 1830 x 1830 x 915 RRBWD/18/18/09/4 500 £604.74 RRSWD/18/09 £139.20 1830 x 1830 x 1220 RRBWD/18/18/12/4 450 £721.66 RRSWD/18/12 £168.43 1830 x 2135 x 457 RRBWD/18/21/04/4 450 £478.33 RRSWD/21/04 £107.60 1830 x 2135 x 610 RRBWD/18/21/06/4 450 £538.76 RRSWD/21/06 £122.71 1830 x 2135 x 762 RRBWD/18/21/07/4 450 £608.68 RRSWD/21/07 £140.19 1830 x 2135 x 915 RRBWD/18/21/09/4 450 £682.07 RRSWD/21/09 £158.54 1830 x 2135 x 1220 RRBWD/18/21/12/4 425 £815.89 RRSWD/21/12 £191.99 1830 x 2440 x 457 RRBWD/18/24/04/4 400 £544.32 RRSWD/24/04 £124.10 1830 x 2440 x 610 RRBWD/18/24/06/4 400 £615.62 RRSWD/24/06 £141.92 1830 x 2440 x 762 RRBWD/18/24/07/4 400 £720.04 RRSWD/24/07 £168.03 1830 x 2440 x 915 RRBWD/18/24/09/4 400 £808.02 RRSWD/24/09 £190.02 1830 x 2440 x 1220 RRBWD/18/24/12/4 400 £974.95 RRSWD/24/12 £231.76 all bays come with uprights, plastic feet, perimeter beams, deck supports & wire mesh decking.
J Rivet increases storage density with its 30mm slim beam profile. 24 J RIVET RACKING Best for Warehouse, Storeroom or Workshop | up to 150kg UDL/shelf Fully flexible, low cost shelving system Our J Rivet system offers unbeatable strength at an incredible price, manufactured to the high quality you have come to expect from one of the UK’s leading suppliers. The shallow J beam profile provides increased storage capacity whilst maintaining excellent strength. To maximise flexibility, our J Rivet range is compatible with our incredible Heavy Rivet range. The system is simple to erect yet has all the strength you are likely to need with a bay load of up to 2800kg. The bays simply tap together with a rubber mallet so you can organize your storage in a fraction of the time it can take with more traditional systems. With the average time to assemble a bay being just 5 minutes, you will be amazed at how easy it is to create large installations. Our lowest priced Rivet Shelving system Run of J Rivet bays connected with Tie Plates J Rivet beam profile J RIVET MALLET £5.79 RR5/WBKT £1.50 RR5/SET4 Set of 4 £6.02 FFM8X50 M8x50 £1.68 RR8/SET4 Set of 4 £5.33 Rubber Mallet Wall Bracket Metal Feet Floor Fixing Tie Plate
Did you know our Heavy Rivet Bays offer heights of up to 3660mm? J RIVET 25 Storeroom Workshop Warehouse 1830 2135 1980 2440 2745 3050 3660 Available with plastic bins Turn to Page 125 for J Rivet with Plastic Bins Strong, sturdy and simple to build J Rivet Bays +Add Extra Shelf H x W x D (mm) Bay Code Shelf Load (kg) Bay Price Shelf Code Additional Shelf Price W915mm 1830 x 915 x 305 JRB/18/09/03/5/BG 150 £141.46 JRS/09/03/GY £18.99 1830 x 915 x 457 JRB/18/09/04/5/BG 150 £164.90 JRS/09/04/GY £23.67 1830 x 915 x 610 JRB/18/09/06/5/BG 150 £188.35 JRS/09/06/GY £28.36 W1220mm 1830 x 1220 x 305 JRB/18/12/03/5/BG 120 £167.51 JRS/12/03/GY £24.19 1830 x 1220 x 457 JRB/18/12/04/5/BG 120 £196.45 JRS/12/04/GY £29.98 1830 x 1220 x 610 JRB/18/12/06/5/BG 120 £225.39 JRS/12/06/GY £35.77 Price includes five levels, uprights, plastic feet, face and side beams and chipboard decks for all levels +For Taller Bays Add Price Extra Height Code Price bays 1980mm RRB/19/--/--/5 £4.17 bays 2135mm RRB/21/--/--/5 £7.41 bays 2440mm RRB/24/--/--/5 £15.05 bays 2745mm RRB/27/--/--/5 £21.53 bays 3050mm RRB/30/--/--/5 £31.02 bays 3660mm RRB/36/--/--/5 £43.99 J Rivet Bay 1830 x 915 x 457mm Guarantee Delivery DAYS Boltless Assembly £141.96 Pricing based on 5 levels Available Heights (mm) (width shown 915mm)
Remember, if your shelving height to depth ratio is greater than 4:1, the bay should be fixed to the floor or to the wall. 26 Best for Warehouse, Storeroom or Workshop | up to 500kg UDL/shelf RIVET DIVIDER SYSTEM Fix divider to any position Will suit any height or depth Rivet Divider System 1830 x 1525 x 457 mm £373.22 Guarantee Delivery DAYS Boltless Assembly Pricing based on 4 levels Our Rivet Divider System provides an effective way to store loose or awkward items. The bays provide multiple locations for separating individual products. The system uses our Heavy Rivet Racking solution with bespoke shelves, dividers and cladding. This creates a cost effective divider systemwith strength and easy installation. As well as standard bays we can offer bespoke designs. All bays are supplied with four levels, uprights, plastic feet, perimeter beams, deck supports, chipboard decking, dividers, brackets and fixings. Dividers are supplied with brackets. Side cladding is constructed from 16mm Chipboard and is supplied with all required fixings and washers. (Some drilling and fixing required). Available in blue/grey and blue/orange. Heavy Rivet Divider System + Extra Compartment Dividers + Side Cladding (1830mm high - Price per Frame) H x W x D (mm) Bay Code Shelf Load (kgs) Bay Price D x H (mm) Code Price H x D (mm) Code Price 1830 x 1525 x 457 RRCD/18/15/04/4 500 £373.22 457 x 571 RRCD/45/57 £12.27 1830 x 457 ZRC/18/04/SC £24.08 1830 x 1525 x 610 RRCD/18/15/06/4 500 £420.04 610 x 571 RRCD/61/57 £13.49 1830 x 610 ZRC/18/06/SC £31.31 1830 x 1830 x 457 RRCD/18/18/04/4 500 £432.72 457 x 571 RRCD/45/57 £12.27 1830 x 457 ZRC/18/04/SC £24.08 1830 x 1830 x 610 RRCD/18/18/06/4 500 £484.41 610 x 571 RRCD/61/57 £13.49 1830 x 610 ZRC/18/06/SC £31.31 1830 x 2440 x 457 RRCD/18/24/04/4 400 £525.33 457 x 571 RRCD/45/57 £12.27 1830 x 457 ZRC/18/04/SC £24.08 1830 x 2440 x 610 RRCD/18/24/06/4 400 £591.14 610 x 571 RRCD/61/57 £13.49 1830 x 610 ZRC/18/06/SC £31.31 RIVET DIVIDER SYSTEM Bay Colour Options For Blue Uprights with Orange Shelves add /BO to the end of your chosen price code. For Blue Uprights with Grey Shelves add /BG to the end of your chosen price code.
Rivet Racking MFC uses a central deck support which not only supports the melamine panel but ties the front and back beams together. HEAVY RIVET MFC 27 Storeroom Workshop Warehouse Heavy Rivet MFC Bays +Adding Extra Shelf H x W x D (mm) Bay Code Shelf Load (kg) Bay Price Shelf Code Additional Shelf Price 1830 x 915 x 610 RRB/M/18/09/06/4 600 £228.75 RRS/M/09/06 £45.21 1830 x 915 x 762 RRB/M/18/09/07/4 600 £258.15 RRS/M/09/07 £52.56 1830 x 915 x 915 RRB/M/18/09/09/4 600 £299.82 RRS/M/09/09 £62.97 1830 x 1220 x 610 RRB/M/18/12/06/4 550 £271.12 RRS/M/12/06 £55.80 1830 x 1220 x 762 RRB/M/18/12/07/4 550 £305.84 RRS/M/12/07 £64.48 1830 x 1220 x 915 RRB/M/18/12/09/4 550 £353.08 RRS/M/12/09 £76.29 1830 x 1830 x 610 RRB/M/18/18/06/4 500 £383.17 RRS/M/18/06 £83.81 1830 x 1830 x 762 RRB/M/18/18/07/4 500 £428.78 RRS/M/18/07 £95.21 1830 x 1830 x 915 RRB/M/18/18/09/4 500 £486.90 RRS/M/18/09 £109.74 1830 x 2440 x 610 RRB/M/18/24/06/4 400 £496.39 RRS/M/24/06 £112.12 1830 x 2440 x 762 RRB/M/18/24/07/4 400 £557.28 RRS/M/24/07 £127.34 1830 x 2440 x 915 RRB/M/18/24/09/4 400 £630.44 RRS/M/24/09 £145.63 +For Taller Bays Add Price Extra Height Code Price bays 1980mm RRB/M/19/--/--/4 £4.17 bays 2135mm RRB/M/21/--/--/4 £7.41 bays 2440mm RRB/M/24/--/--/4 £15.05 bays 2745mm RRB/M/27/--/--/4 £21.53 bays 3050mm RRB/M/30/--/--/4 £31.02 bays 3660mm RRB/M/36/--/--/4 £43.99 Heavy Rivet MFC Bays come with four White melamine shelf levels as standard. Bay price also includes uprights, plastic feet, face and side beams. The Heavy Rivet MFC offers the same incredible rigidity of the standard model combined with clean, wipe down melamine shelving. Heavy Rivet MFC offers incredible shelf loading capacities of up to 500kg. The hard wearing edged White MFC shelving finish offers additional resilience and is extremely easy to maintain. Heavy Rivet beam profile 1830, 2135 & 2440 wide HEAVY RIVET MFC £228.75 Pricing based on 4 levels Bay Colour Options For Blue Uprights with Orange Shelves add /BO to the end of your chosen price code. For Blue Uprights with Grey Shelves add /BG to the end of your chosen price code.
Integral back stop Profiled sides for extra strength Nestable design – space saving Large labelling area Semi-open fronted design 7 divider positions in each bin Dividers positively slot into the bin 1 2 3 4 5 6 7 Features 3 4 5 6 7 2 1 28 RIVET RACKING SHELF BINS Best for Warehouse, Storeroom or Workshop | up to 600kg UDL/shelf Rivet racking with shelf bins provides high density small parts solutions. Shelf Bins & Additional Dividers Shelf Bins D x W x H(mm) Code Colour Price 300x280x200mm SFB302820 Blue £8.93 450x280x200mm SFB452820 Blue £13.01 450x420x200mm SFB454220 Blue £18.30 600x280x200mm SFB602820 Blue £16.32 600x420x200mm SFB604220 Blue £24.48 Add Dividers W x H(mm) Code Colour Price 280x200mm SFD2820 Black £2.54 420x200mm SFD4220 Black £3.53 £8.93 Guarantee Delivery DAYS If you need a strong, robust and versatile bin storage solution, at a competitive price – then look no further. Our new range of Shelf Bins have been designed to offer a range of bins in “Big Sizes” for storing large parts or increased volumes. They can fit both small parts shelving systems as well as larger bays, such as Rivet or Longspan. They have many new features, such as internal dividers that securely locate into 7 different locations. There is also an integral back stop allowing the bin to be suspended out from the shelving, for ease of picking. With a semi-open front and a large labelling area below, ensures items can be identified quickly. The bins are available in Blue shockproof plastic and can be nested when not in use to save space. 300mm 450mm 600mm 420mm 280mm
29 Storeroom Workshop Warehouse RIVET RACKING SHELF BINS If you can’t find the right configuration for your application, please contact the sales team as they are here to help! Rivet Racking Bays with Bins £398.81 £499.88 £507.16 Rivet Racking with 280mm Shelf Bins H x W x D (mm) Bin Qty Code Price 1980 x 915 x 305 18 RRSFB03A £398.81 1980 x 915 x 457 18 RRSFB04A £514.44 1980 x 915 x 610 18 RRSFB06A £613.73 Rivet Racking with 420mm Shelf Bins H x W x D (mm) Bin Qty Code Price 1980 x 915 x 457 12 RRSFB04B £499.88 1980 x 915 x 610 12 RRSFB06B £613.73 Rivet Racking with mixed 420mm & 280mm Shelf Bins H x W x D (mm) Bin Qty Code Price 1980 x 915 x 457 15 RRSFB04C £507.16 1980 x 915 x 610 15 RRSFB06C £613.73 Price includes Rivet Racking bay with 7 shelf levels and 18 No. shelf bins 280mm wide.(Dividers not included) Price includes Rivet Racking bay with 7 shelf levels and 12 No. 420mm wide shelf bins.(Dividers not included) Price includes Rivet Racking bay with 7 shelf levels and 9 No. 280mm and 6 No. 420mm wide shelf bins. (Dividers not included) Pricing based on 7 levels
If you cannot find the right size for your application, please call us for more customised options. 30 RIVET CABLE REEL RACKS Best for Cable storage | up to 70kg UDL/rail Cable Reel Rack - 1830mm high H x W x D (mm) Code Tube Load (kg) Price 1830 x 915 x 610 RRCB/18/09/06/4/BG 70 £289.41 1830 x 1220 x 610 RRCB/18/12/06/4/BG 60 £348.68 Keep cable reels organised A new solution for organising and dispensing cable and items stored in reels. The simple side beam supports a 25mm diameter tube which can hold a variety of drums or reels. The beam is notched so the tubes can be placed in 5 different positions. Each level is then fitted with a face beam to enable the material to be passed to the user and conveniently cut to length. The units come as either static racks or as a low level mobile trolley. Bays are available in either 915 or 1220mm wide and 610mm deep. Cable Reel Trolley 915 x 915 x 610 mm Braked castors for additional safety 5 different positions for the tube Mobile Cable Reel Storage / Bench H x W x D (mm) Code Tube Load (kg) Price 880 x 915 x 610 RRCT/09/09/06/2/BG 70 £311.63 Price includes uprights, base frame with swivel castors (2 braked), chipboard decks and two levels with notched beams, support beams and 4 zinc coated tubes Price includes uprights, plastic feet, chipboard decks and four levels with notched beams, support beams and 8 zinc coated tubes Cable Reel Rack 1830 x 915 x 610 mm Cable Reel Trolley 915 x 915 x 610 mm £289.41 Guarantee Delivery DAYS Assembly £311.63
Need wider heavy duty garment rails? See our Longspan garment solution on pg.77 RIVET GARMENT RACKS 31 Storeroom Workshop Retail The perfect storage solution for any bulk garment hanging requirement. All constructed fromRivet racking components for simplicity and ease of assembly. The 25mm zinc coated tube slots into place on the notched beams and can be located in five different positions. This can provide a single rail centrally positioned or two rails located on each face of the rack providing twice the capacity. Each storage level can be adjusted every 38mm. Price includes uprights, plastic feet, chipboard decks for top and bottom shelves, two levels with notched beams, support beams and 2 or 4 zinc coated tubes Single Rail Garment Bay - 2 Levels H x W x D (mm) Code Tube Load (kg) Bay 2135 x 915 x 610 RRGB/SG/21/09/06/2/BG 70 £132.95 2135 x 1220 x 610 RRGB/SG/21/12/06/2/BG 60 £158.88 Double Rail Garment Bay - 2 Levels H x W x D (mm) Code Tube Load (kg) Bay 2135 x 915 x 610 RRGB/DG/21/09/06/2/BG 70 £156.46 2135 x 1220 x 610 RRGB/DG/21/12/06/2/BG 60 £190.37 Two single rail garment bays connected with tie plates Single Rail Garment Bay 2135 x 915 x 610 mm Double Rail Garment Bay 2135 x 915 x 610 mm Bulk garment hanging storage solution RIVET GARMENT RACKS Guarantee Delivery DAYS Boltless Assembly £132.95 £156.46
32 RIVET RACKING ARCHIVE Best for Warehouse, Storeroom or Office | up to 500kg UDL/shelf For storing small components, please check our high density storage solutions on p.92 Our Rivet Archive range is the perfect solution for high density paper storage and archiving. Our range of Archive Storage Solutions is formed of our Heavy Rivet range combined with high quality Heavy Duty Archive boxes. Each individual box offers a loading capacity of up to 20kg, with shelves supporting a UDL of up to 500kg. Rivet Archive is available in two depths, three heights and two widths and is perfect for the storeroom, workshop or warehouse. Need More Boxes? Our Heavy Duty Archive box and lid are designed to hold 20kgs of paper. The robust construction means documents will be securely and safely stored. The boxes come flat packed and are easy to assemble. Boxes come with handle holes for easy transportation and the internal dimensions are 250H x 330W x 390D. Utilise space with our high density Archive solution Double Box Deep Rivet Archive 3050 x 1830 x 915 with 100 boxes on 5 levels Archive Boxes – Pack Of 10 H x W x D (mm) Code Price 270 x 350 x 430 AK0020AB/10 £50.36 £50.36 per pack ARCHIVE STORAGE SOLUTIONS
RIVET RACKING ARCHIVE 33 Rivet Racking uses a central deck support which not only supports the chipboard panel but ties the two face beams together. Storeroom Workshop Warehouse Rivet Racking Archive Storage Rivet Archive - 1525mmWide Rivet Archive - 1830mmWide H x W x D (mm) Shelf Levels Code Box Qty Price Single Box Deep Depth 457mm 1830 x 1525 x 457mm (1966mm) 3 RRAK15/24 24 £329.92 2440 x 1525 x 457mm (2614mm) 4 RRAK15/32 32 £438.97 3050 x 1525 x 457mm (3262mm) 5 RRAK15/40 40 £548.95 Double Box Deep Depth 915mm 1830 x 1525 x 915mm (1966mm) 3 RRAK15/48 48 £541.94 2440 x 1525 x 915mm (2614mm) 4 RRAK15/64 64 £721.66 3050 x 1525 x 915mm (3262mm) 5 RRAK15/80 80 £902.31 H x W x D (mm) Shelf Levels Code Box Qty Price Single Box Deep Depth 457mm 1830 x 1830 x 457mm (1966mm) 3 RRAK18/30 30 £404.76 2440 x 1830 x 457mm (2614mm) 4 RRAK18/40 40 £538.76 3050 x 1830 x 457mm (3262mm) 5 RRAK18/50 50 £673.68 Double Box Deep Depth 915mm 1830 x 1830 x 915mm (1966mm) 3 RRAK18/60 60 £657.76 2440 x 1830 x 915mm (2614mm) 4 RRAK18/80 80 £876.09 3050 x 1830 x 915mm (3262mm) 5 RRAK18/100 100 £1,095.34 D 457 D 915 H 1830 Available Depth (mm) single box double box Available Heights (mm) H 3050 H 2440 Available Heights (mm) H 3050 D 457 H 2440 D 915 H 1830 Available Depth (mm) single box double box Single Box Deep Rivet Archive 1830 x 1830 x 457 with 30 boxes on 3 levels Price includes uprights, plastic feet, perimeter beams, deck supports, chipboard decks and archive boxes with lids £329.92 *Height to top of top box *Height to top of top box Available in Blue/Orange (/BO) or Blue/Grey (/BG) Guarantee Delivery DAYS Boltless Assembly
RIVET BASED BENCHES & WORKSTATIONS A cost effective answer to solve your busy packing and assembly areas. Strong and simple to build these workbenches come in a wide range of sizes that will suit most applications. We now offer 2 styles of worktops - Chipboard and White MFC with the MFC tops being edged with a hard wearing 1mm PVC edging. • Easy to build and adjust • Based on our Rivet Racking platform • Guaranteed delivery in 5 days • Available in blue/grey and blue/orange • Other sizes available 34 RIVET BENCHES Best for Warehouse, Storeroom or Workshop | up to 400kg UDL/shelf
Heights Widths Depths Application Construction Loadings Great value heavy duty Workbenches built on our Rivet Racking system Worktop height (mm) 915 Top shelf height (mm) 1830 Workbench widths (mm) 915, 1220, 1525, 1830, 2135, 2440 Workstation widths (mm) 915, 1220, 1830, 2440 Packing Bench widths (mm) wide: 1525, 1830 long: 915, 1220 Workbench depths (mm) 762, 915 Workstation depths (mm) 915 Packing Bench depths (mm) wide: 915 long: 1830, 2135 Environment Workshop, Warehouse, Storeroom Usage Order Processing, Packing, Manufacturing Split Uprights: Steel Blue RAL5010 Beams: Steel Grey RAL7038 Orange RAL2002 Worktops/Shelves Chipboard or White MFC Level UDL up to 400kg Max Bench Load 600kg Guarantee Delivery DAYS Boltless Assembly RIVET BENCHES 35 Storeroom Workshop Warehouse
Chipboard Top Full Undershelf Workstation with Chipboard Tops 1830 x 1830 x 915 £261.16 Full Undershelf Workstation - Chipboard Order more and save money (Price for Each) H x W x D (mm) Code Price for 1 Price for 2 Price for 3+ 1830 x 915 x 915 RRWS/18/09/09/03 £330.62 £295.89 £261.16 1830 x 1220 x 915 RRWS/18/12/09/03 £369.40 £334.67 £299.94 1830 x 1830 x 915 RRWS/18/18/09/03 £486.43 £451.71 £416.98 1830 x 2440 x 915 RRWS/18/24/09/03 £570.13 £535.40 £500.67 Price includes uprights, plastic feet, all necessary beams and shelves. Total workbench capacity = 600kgs** (** each shelf to carry no more than 400kgs. Floor fixing not included.) Simple to build and incredibly strong. These picking and assembly workbenches come with a strong worktop, 915mm high and two storage shelves above (305mm deep). RIVET WORKSTATIONS Guarantee Delivery DAYS Boltless Assembly Blue & Orange Combination Available 36 RIVET WORKSTATIONS Best for Workshop, Storeroom or Warehouse From Prices based on order of 3 Items +
